Product data
Download product data| Part-No. | Part number |
| G | Weight in grams |
| L | Length |
| S | Diameter |
| PART NO. | G | L | S |
|---|---|---|---|
| AE0008A | 28 | 100 | 8 mm |
| AE0009A | 30 | 110 | 9 mm |
| AE0010A | 35 | 115 | 10 mm |
| AE0011A | 45 | 125 | 11 mm |
| AE0012A | 55 | 135 | 12 mm |
| AE0013A | 70 | 145 | 13 mm |
| AE0014A | 70 | 145 | 14 mm |
| AE0015A | 90 | 155 | 15 mm |
| AE0016A | 90 | 155 | 5/8 inches |
| AE0016A | 90 | 155 | 16 mm |
| AE0017A | 115 | 170 | 17 mm |
| AE0018A | 115 | 170 | 18 mm |
| AE0019A | 155 | 185 | 19 mm |
| AE0019A | 155 | 185 | 3/4 inches |
| AE0020A | 155 | 185 | 20 mm |
| AE0021A | 180 | 200 | 21 mm |
| AE0022A | 180 | 200 | 22 mm |
| AE0023A | 250 | 220 | 23 mm |
| AE0024A | 250 | 220 | 24 mm |
| AE0025A | 350 | 240 | 25 mm |
| AE0026A | 350 | 240 | 26 mm |
| AE0027A | 350 | 240 | 27 mm |
| AE0028A | 420 | 260 | 28 mm |
| AE0029A | 420 | 260 | 29 mm |
| AE0030A | 420 | 260 | 30 mm |
| AE0032A | 550 | 285 | 32 mm |
| AE0033A | 550 | 285 | 33 mm |
| AE0034A | 550 | 285 | 34 mm |
| AE0035A | 710 | 310 | 35 mm |
| AE0036A | 710 | 310 | 36 mm |
| AE0037A | 710 | 310 | 37 mm |
| AE0038A | 710 | 310 | 38 mm |
| AE0041A | 980 | 340 | 41 mm |
| AE0042A | 980 | 340 | 42 mm |
| AE0046A | 1160 | 375 | 46 mm |
| AE0047A | 1160 | 375 | 47 mm |
| AE0050A | 1660 | 415 | 50 mm |
| AE0052A | 1660 | 415 | 52 mm |
| AE0054A | 2210 | 455 | 54 mm |
| AE0055A | 2210 | 455 | 55 mm |
| AE0056A | 2210 | 455 | 56 mm |
| AE0058A | 2940 | 505 | 58 mm |
| AE0060A | 2940 | 505 | 60 mm |
| AE0063A | 2940 | 505 | 63 mm |
| AE0065A | 4000 | 555 | 65 mm |
| AE0067A | 4000 | 555 | 67 mm |
| AE0070A | 4000 | 555 | 70 mm |
| AE0071A | 4000 | 555 | 71 mm |
| AE0075A | 4800 | 615 | 75 mm |
| AE0077A | 4800 | 615 | 77 mm |
| AE0080A | 4800 | 615 | 80 mm |
| AE0082A | 6250 | 690 | 82 mm |
| AE0085A | 6250 | 690 | 85 mm |
| AE0088A | 6250 | 690 | 88 mm |
| AE0090A | 6250 | 690 | 90 mm |
| AE0094A | 8300 | 770 | 94 mm |
| AE0095A | 8300 | 770 | 95 mm |
| AE0100A | 8300 | 770 | 100 mm |
| BE0008A | 28 | 100 | 5/16 inches |
| BE0009A | 35 | 115 | 3/8 inches |
| BE0010A | 35 | 115 | 13/32 inches |
| BE0011A | 45 | 125 | 7/16 inches |
| BE0013A | 70 | 145 | 1/2 inches |
| BE0014A | 70 | 145 | 9/16 inches |
| BE0015A | 90 | 155 | 19/32 inches |
| BE0018A | 115 | 170 | 11/16 inches |
| BE0020A | 155 | 185 | 25/32 inches |
| BE0021A | 180 | 200 | 13/32 inches |
| BE0022A | 180 | 200 | 7/8 inches |
| BE0024A | 250 | 220 | 15/16 inches |
| BE0025A | 250 | 220 | 31/32 inches |
| BE0026A | 350 | 240 | 1 inches |
| BE0027A | 350 | 240 | 1.1/16 inches |
| BE0029A | 420 | 260 | 1.1/8 inches |
| BE0030A | 420 | 260 | 1.3/16 inches |
| BE0032A | 550 | 285 | 1.1/4 inches |
| BE0033A | 550 | 285 | 1.5/16 inches |
| BE0035A | 710 | 310 | 1.3/8 inches |
| BE0037A | 710 | 310 | 1.7/16 inches |
| BE0038A | 710 | 310 | 1.1/2 inches |
| BE0039A | 980 | 340 | 1.9/16 inches |
| BE0041A | 980 | 340 | 1.5/8 inches |
| BE0043A | 1160 | 375 | 1.11/16 inches |
| BE0044A | 1160 | 375 | 1.3/4 inches |
| BE0046A | 1160 | 375 | 1.13/16 inches |
| BE0048A | 1660 | 415 | 1.7/8 inches |
| BE0051A | 1660 | 415 | 2 inches |
| BE0052A | 2210 | 455 | 2.1/16 inches |
| BE0054A | 2210 | 455 | 2.1/8 inches |
| BE0056A | 2210 | 455 | 2.3/16 inches |
| BE0057A | 2210 | 455 | 2.1/4 inches |
| BE0059A | 2940 | 505 | 2.5/16 inches |
| BE0060A | 2940 | 505 | 2.3/8 inches |
| BE0062A | 2940 | 505 | 2.7/16 inches |
| BE0064A | 4000 | 555 | 2.1/2 inches |
| BE0065A | 4000 | 555 | 2.9/16 inches |
| BE0067A | 4000 | 555 | 2.5/8 inches |
| BE0070A | 4000 | 555 | 2.3/4 inches |
| BE0071A | 4000 | 555 | 2.13/16 inches |
| BE0075A | 4800 | 615 | 2.15/16 inches |
| BE0076A | 4800 | 615 | 3 inches |
| BE0079A | 4800 | 615 | 3.1/8 inches |
| BE0083A | 6250 | 690 | 3.1/4 inches |
| BE0086A | 6250 | 690 | 3.3/8 inches |
| BE0089A | 6250 | 690 | 3.1/2 inches |
| BE0092A | 8300 | 770 | 3.5/8 inches |
| BE0095A | 8300 | 770 | 3.3/4 inches |
| BE0098A | 8300 | 770 | 3.7/8 inches |
